OMNIPV SOLAR WALL EXHAUST FAN

OMNIPV SOLAR WALL EXHAUST FAN

Regular price $239.99
Regular price Sale price $239.99
Sale Sold out
Shipping calculated at checkout.

✦ Description

The Omni PV solar wall exhaust fan functions in several ways to keep your place cool and comfortable. Its design includes the following features:

  • It is solar-powered, so there is no running cost

  • It reduces the need for air-conditioning, reducing energy bills

  • It is easy to install and is compatible with tile, wood, metal, and dry walls. Square mounting frame on fan and mounting rack on solar panel are equipped for quick and flexible installation

  • It reduces humidity and promotes airflow, which can lower temperature by up to 30 ̊F

  • It reduces condensation build-up at your place

  • It has a brushless DC motor for quiet operation

  • High-quality material is used for each part to ensure a long service life

  • In the cooler months, the thermostat control prevents heat loss and keeps the place warm

  • The fan is corrosion resistant and is suitable for coastal regions



✦ Specification

Model

PVSFR-35

Fan

300mm Balanced Blade (×5), with Low Resistance

Capacity

1200 CFM

Motor

35 Watts, 6-19 VDC, 1600 rpm Max, Brushless Motor with Double Shielded Ball Bearings

Noise

< 45 dBA Automatic

Automatic Shut Off

< 77 °F +/- 5%

Fan Dimensions

14 x 14 x 5 in

Fan Weight

6 lbs

Construction

Aluminum Top Cover, Aluminum Body, Steel Brackets and Stainless-Steel Fasteners

Color

Black Powder Coated

Solar Panel Type

Monocrystalline PV, Heavy Duty Frame, 3mm Tempered Glass

Solar Panel Output

35 Watts, 18 VDC

Solar Panel Dimensions

19.7 x 18.1 x 0.7 in

Solar Panel Weight

6 lbs

Packing Dimensions

20.9 x 22.4 x 9.4 in

Packing Weight

19.4 lbs

Warranty

2 Year Limited Warranty (10 Years on Solar Panel)
